Brake Components for 1995 GMC Jimmy
No.
Part # / Description / Price
Price
1
Brake Drum
GM
GM Positions: Left
Description: S-series. Aluminum. Chevrolet, olds, pont. 9 1/2 brake. Buick. LeSabre, estate wagon. 9 1/2 brakes.
2
M12x1.5x40 Multi-Purpose Bolt GM
GM Description: This GM Genuine Part is designed, engineered, and tested to rigorous standards and is backed by General Motors
MSRP $5.84
$3.71
MSRP $5.84
$3.71
4
Backing Plate GM
GM Positions: Right
Description: Astro, Safari. Right. 7.5 ring gear. Drum brakes, with 4 wheel abs. Drum brakes, 1993-97.
4
Backing Plate GM
GM Positions: Left
Description: Astro, Safari. Left. 7.5 ring gear. Sedan, 9.5 brake. Drum brakes, with 4 wheel abs. Drum brakes, 1993-97.
5
Rear Drum Brake Shoe Set GM
GM Description: S-series. Astro, Safari. All models. Drum brakes, 1993-97. Rust-preventive coating to help protect against corrosion
Direct fit; no retrofitting is required
This GM Genuine Part is designed, engineered, and tested to rigorous standards and is backed by General Motors
MSRP $156.58
$86.90
MSRP $156.58
$86.90
7
Brake Hose GM
GM Positions: Left
Description: With disc brake, 2wd. Wrecker Package. ZR2 Higher Wider Package. S-series. Disc brakes. Blazer. 4 door.
7
Acdelco™ Brake Hose GM
GM Positions: Right
Notes: PARTS: Order by description.
Description: S-series. With disc brake, 4wd. Disc brakes. S10/Sonoma. ZR2 Higher Wider Package. Blazer. 2 door. Without high wider pkg.. 4wd.
7
Rear Hydraulic Brake Hose GM
GM Description: S-series. Drum brakes. Pick-up. 2wd. Blazer, Jimmy. 4 door. Pick-up. 4wd. Without high wider pkg. 2nd design. With drum brake, 4 door. Bravada. Location-To Frame. This GM Genuine Part is designed, engineered, and tested to rigorous standards and is backed by General Motors
7
Rear Hydraulic Brake Hose GM
GM Positions: Right
Notes: PARTS: Order by description.
Description: S-series. With disc brake, 4wd. Disc brakes. S10/Sonoma. Blazer. 2 door. Without high wider pkg.. 4wd. This GM Genuine Part is designed, engineered, and tested to rigorous standards and is backed by General Motors
7
Brake Hydraulic Hose GM
GM Description: S-series. Drum brakes. Pick-up. 4wd. With high wider pkg. Blazer, Jimmy. 2 door. With drum brake, 2 door. ZR2 Higher Wider Package. Center Feed.
No.
Part # / Description / Price
Price
1
Disc Brake Caliper GM
GM Positions: Left
Description: S-series. 2wd. Without performance pkg. Left. Pick-up. 2wd, 1995-97.
1
Disc Brake Caliper GM
GM Positions: Right
Description: S-series. 2wd. Without performance pkg. Right. Pick-up. 2wd, 1995-97.
2
Front Driver Side Brake Dust Shield 2 GM
GM Positions: Left
Notes: PARTS: Part includes ABS speed sensor.
Description: S-series. 2wd. Left. 2wd, 1995-97. 2wd, 4 door. 2wd, 4.3L. Shield Assembly. Incl.ABS Wheel Speed Sensor Wire Harness. 2WD. all. This GM Genuine Part is designed, engineered, and tested to rigorous standards and is backed by General Motors
2
Splash Shield 2 GM
GM Positions: Right
Notes: PARTS: Part includes ABS speed sensor.
Description: S-series. 2wd. Right. 2wd, 1995-97. 2wd, 4 door. 2wd, 4.3L. Shield Assembly. Incl.ABS Wheel Speed Sensor Wire Harness. 2WD. all.
3
Front Inner Wheel Bearing GM
GM Positions: Right
Description: Incl.Race. Exc.Heavy Duty Chassis. Gvw 4,900 lbs. Gvw 5,600 lbs. Help minimize wear and friction in a variety of applications on your vehicle
MSRP $44.40
$24.76
MSRP $44.40
$24.76
4
Front Inner Wheel Bearing Seal GM
GM Positions: Left
Description: This GM Genuine Part is designed, engineered, and tested to rigorous standards and is backed by General Motors
5
Rotor GM
GM Positions: Right
Notes: PARTS: Part includes studs, sensor ring and bearings.
Description: Pick-up. S-series. 2wd. Long bed. 2wd, 1995-97.
6
Front Outer Wheel Bearing GM
GM Positions: Right
Description: S-series. All models. Without performance package. Caballero, El Camino. 2wd, 1995-97. Outer, with performance pkg. Incl.Race. Allows the wheel to rotate with minimal friction
Supports the weight of the vehicle
Maximum lateral stiffness for optimum ride, handling, and driving dynamics
GM OE parts are built to help withstand potholes and designed to maximize seal life
GM OE bearing designs are dimensionally optimized to work with their mating parts
MSRP $20.16
$11.24
MSRP $20.16
$11.24
6
Acdelco™ Front Wheel Bearing GM
GM Positions: Right
Description: Incl.Race. S-series. All models. Without performance package. Exc.Performance Package. Caballero, El Camino. 2wd, 1995-97. Outer, with performance pkg.
7
Front Hydraulic Brake Hose Assembly GM
GM Positions: Left
Description: S-series. 2wd. Pick-up. 2wd, 1995-97. Includes OE features such as brackets, grommets, molded plastic guards, and wire clips to provide correct fit and easy installation
Premium brass fittings provide an excellent hydraulic seal
Performs to standards required by OE manufacturers ensuring optimal protection, service life, and safety
MSRP $23.04
$12.84
MSRP $23.04
$12.84
7
8
Disc Brake Pad Set GM
GM Description: S-series. Pick-up. 2wd. 2wd, 1998-05. 4wd. 2wd, 1995-97. Bonded Linings.
2 This part contains hazardous materials. Extra shipping costs apply.
