Rear Suspension/Rear Suspension for 1997 Buick Riviera

Select Rear Suspension Part

1997 Buick Riviera

Change vehicle

Rear Suspension/Rear Suspension for 1997 Buick Riviera #1
No. Part # Part # / Description List Price Price
N/A 19116057 19116057 / HVAC Blower Motor Relay

Control Relay

ALL MODELS

$16.96 $9.20
N/A 22153443 22153443 / Dehydrator

Dryer

ALL MODELS

$142.32 $88.03
N/A 12494811 12494811 / Compressor Assembly

Compressor

ALL MODELS

- -
N/A 25604734 25604734 / Stabilizer Bar Bushing

Bushings

ALL MODELS

- -
N/A 22153656 22153656 / Sensor

ALL MODELS

- -
N/A 12494812 12494812 / Compressor Head

ALL MODELS

- -
N/A 22124393 22124393 / Seat Back Cover

Filter

ALL MODELS

$25.91 $16.03
1 88890012 88890012 / Suspension Cross-Member

Cross-member

ALL MODELS

- -
2 7470555 7470555 / Hub & Bearing

ALL MODELS

$474.88 $112.24
3 25820031 25820031 / Control Arm

Lower Control Arm

ALL MODELS; LEFT

$280.21 $173.30
3 25820033 25820033 / Control Arm

Lower Control Arm

ALL MODELS; RIGHT

$278.69 $172.35
4 25557623 25557623 / Lower Control Arm Outer Bushing

Bushings

ALL MODELS

- -
5 19299843 19299843 / Shock Absorber

RIVIERA; LEFT

- -
6 25655478 25655478 / Coil Spring

RIVIERA

- -
7 25645090 25645090 / Adjust Link

ALL MODELS; RIGHT

- -
7 25645089 25645089 / Adjust Link

ALL MODELS; LEFT

$304.28 $188.18
8 26037362 26037362 / Tie Rod Assembly

Tie Rod

ALL MODELS; RIGHT

- -
8 26037360 26037360 / Tie Rod Assembly

Tie Rod

ALL MODELS; LEFT

- -
9 25604384 25604384 / Stabilizer Bar

ALL MODELS

- -
10 25689592 25689592 / Stabilizer Bar Bracket

Bracket

ALL MODELS

$18.72 $11.58
11 25940977 25940977 / Stabilizer Link

Link

ALL MODELS

$22.16 $13.70
Rear Suspension/Rear Suspension for 1997 Buick Riviera #2
No. Part # Part # / Description List Price Price
1 25820031 25820031 / Control Arm

Lower Control Arm, LEFT

$280.21 $173.30
1 25820033 25820033 / Control Arm

Lower Control Arm, RIGHT

$278.69 $172.35
2 25557623 25557623 / Lower Control Arm Outer Bushing

Lower Control Arm Bushing, LEFT

- -
2 25557623 25557623 / Lower Control Arm Outer Bushing

Lower Control Arm Bushing, RIGHT

- -
3 25604378 25604378 / Control Arm Bolt

Lower Control Arm Bolt, LEFT

$8.19 $5.07
3 25604378 25604378 / Control Arm Bolt

Lower Control Arm Bolt, RIGHT

$8.19 $5.07
4 10271003 10271003 / Lower Control Arm Ball Stud

Ball Stud, RIGHT

$10.86 $6.72
4 10271003 10271003 / Lower Control Arm Ball Stud

Ball Stud, LEFT

$10.86 $6.72
5 26037360 26037360 / Tie Rod Assembly

Outer Tie Rod, LEFT

- -
5 26037362 26037362 / Tie Rod Assembly

Outer Tie Rod, RIGHT

- -
6 26049394 26049394 / Outer Tie Rod Seal

Outer Tie Rod Seal, LEFT

- -
6 26049394 26049394 / Outer Tie Rod Seal

Outer Tie Rod Seal, RIGHT

- -
7 7837219 7837219 / Inner Tie Rod Bolt

Outer Tie Rod Bolt, RIGHT

- -
7 7837219 7837219 / Inner Tie Rod Bolt

Outer Tie Rod Bolt, LEFT

- -
8 25645089 25645089 / Adjust Link

Inner Tie Rod, LEFT

$304.28 $188.18
8 25645090 25645090 / Adjust Link

Inner Tie Rod, RIGHT

- -
9 11519299 11519299 / Lateral Arm Adjust Bolt

Adjust Bolt, LEFT

$5.88 $3.63
9 11519299 11519299 / Lateral Arm Adjust Bolt

Adjust Bolt, RIGHT

$5.88 $3.63
10 25616847 25616847 / Adjust Bolt Cam (THIS PART CAN NOT BE SPECIAL ORDERED)

Adjust Bolt Cam (THIS PART CAN NOT BE SPECIAL ORDERED), LEFT

- -
10 25616847 25616847 / Adjust Bolt Cam (THIS PART CAN NOT BE SPECIAL ORDERED)

Adjust Bolt Cam (THIS PART CAN NOT BE SPECIAL ORDERED), RIGHT

- -
11 22078069 22078069 / Spring

Spring, LEFT

- -
11 22078069 22078069 / Spring

Spring, RIGHT

- -
12 25703339 25703339 / Coil Spring Insulator

Spring Insulator, RIGHT

UPPER

$31.66 $19.58
12 25703339 25703339 / Coil Spring Insulator

Spring Insulator, LEFT

UPPER

$31.66 $19.58
13 25627582 25627582 / Insulator

Spring Insulator, RIGHT

LOWER

$26.96 $16.68
13 25627582 25627582 / Insulator

Spring Insulator, LEFT

LOWER

$26.96 $16.68
14 19299843 19299843 / Shock Absorber

Shock, RIGHT

- -
14 19299843 19299843 / Shock Absorber

Shock, LEFT

- -
15 25694853 25694853 / Shock Absorber Cover

Shock Cover, RIGHT

$10.86 $6.72
15 25694853 25694853 / Shock Absorber Cover

Shock Cover, LEFT

$10.86 $6.72
16 15251008 15251008 / Shock Mount Reinforcement

Reinforcement, LEFT

$5.61 $3.46
16 15251008 15251008 / Shock Mount Reinforcement

Reinforcement, RIGHT

$5.61 $3.46
17 15887238 15887238 / Bracket

Lower Bracket, LEFT

$27.51 $17.01
17 25650403 25650403 / Bracket

Lower Bracket, RIGHT

$18.74 $11.59
18 15237958 15237958 / Front Insulator

Cushion, RIGHT

FRONT

$36.01 $22.26
18 15237959 15237959 / Front Insulator

Cushion, LEFT

FRONT

$36.01 $22.26
19 10397249 10397249 / Rear Insulator

Cushion

REAR

$42.17 $26.07
20 88890012 88890012 / Suspension Cross-Member

Suspension Support

- -
21 25636113 25636113 / Mount Bracket

Mount Bracket, LEFT

EXHAUST HANGER

- -
21 25636112 25636112 / Mount Bracket

Mount Bracket, RIGHT

EXHAUST HANGER

- -
No. Part # Part # / Description List Price Price
N/A 25611428 25611428 / Outer Tie Rod Nut

Outer Tie Rod Nut, LEFT

$1.22 $0.75
N/A 11076431 11076431 / Lower Control Arm Cotter Pin

Outer Tie Rod Pin, RIGHT

$4.51 $2.79
No. Part # Part # / Description List Price Price
N/A 11076431 11076431 / Lower Control Arm Cotter Pin

Outer Tie Rod Pin, LEFT

$4.51 $2.79
N/A 25611428 25611428 / Outer Tie Rod Nut

Outer Tie Rod Nut, RIGHT

$1.22 $0.75
